Learn to model and 3D print your own jewelry projects using Rhino 3D -THE industry standard for CAD jewelry design. With Rhino 3D you can create any type of jewelry, in any 3D shape you can imagine. Design, create and render custom jewelry designs to 3D print in a multitude of materials, from plastic to precious metals.
You don't need to have any prior background in Rhino, or even CAD design for this course. I will take you from the basics of the Rhino interface, and common Rhino commands and skills you will need to complete this course. This course comes in four parts. Begin with the basics and learning the Rhino interface. Next, dig into the essentials, with an overview of common Rhino commands and tools. In Rhino Skills, you will learn more complicated tools, once you have a better understanding of how the program functions. Finally, in the projects portion of the course, you will work through a set of increasingly complex ring projects. Begin with a plain wedding band, and finish with a set of custom engagement rings.
No 3D printer? No problem! When your designs are complete, get them printed with the multitude of online 3D printing services available. You can have them in hand within weeks! If you are a maker, designer, student, artist, or just interested in learning more about 3D printing and CAD design in general, this is the course for you!
Happy designing...
- Introducing Rhino Essentials (0:56)
- The Ortho Constraint (2:08)
- Working on the Construction Plane (2:16)
- Working with Lines (3:27)
- Creating 2D Shapes (2:37)
- Creating 3D Shapes (2:30)
- The Move Command (1:54)
- Using Object Snaps (3:44)
- Creating Arcs (2:40)
- The Cap Command (2:31)
- Creating Pipes (3:33)
- Mirroring Objects (2:11)
- Offsetting Objects (2:20)
- Copying Objects (4:20)
- Introduction to Rhino Skills (2:44)
- Array Linear and Array Polar (3:58)
- Scaling Objects (4:57)
- Rotating Objects (5:01)
- Trim and Join Objects (4:30)
- Boolean Operations: Boolean Difference and Union (6:11)
- Working with Surfaces Part 1: Revolve (3:39)
- Working with Surfaces Part 2: Rail Sweeps (5:44)
- Working with Surfaces 3: Surfaces from Corner Points and Planar Curves (4:10)
- Working with Surfaces 4: Surface from a Network of Curves (5:03)
- Flow Surfaces onto Objects (5:42)
- Fillet Corners and Edges (4:07)
- Cut Planes and the Splitting Objects (3:59)
- Introducing Rhino Projects (1:15)
- Project 1: Create a Basic Wedding Band in Two Ways (15:10)
- Project 2: Create a Waveform Ring (9:37)
- Project 3: Create a Three-Band Ring (9:49)
- Project 4: Create a Minimalist Ring (11:50)
- Project 5: Create an Initial Script Ring (11:10)
- Project 6: Create a Step-up Ring Band (7:19)
- Project 7: Create an Engraved Ring Band (17:15)
- Project 8: Create a Graduated Sphere Ring (15:00)
- Project 9: Create a 'Solid Diamond' Ring (12:46)
- Project 10: Create a Custom Signet Ring (22:21)
- Project 11: Create a Round Brilliant Diamond & Settings Part 1: Diamond Templates (16:15)
- Project 11: Create a Round Brilliant Diamond & Settings Part 2: Basket Setting (11:24)
- Project 11: Create a Round Brilliant Diamond & Settings Part 3: Crown Setting (18:45)
- Project 11: Create a Round Brilliant Diamond & Settings Part 4: High-Shouldered Ring Shank (10:47)
- Project 11: Create a Round Brilliant Diamond & Settings Part 5: Knife-Edged Ring Shank (9:14)
- Project 11: Create a Round Brilliant Diamond & Settings Part 6: Basket-Set Solitaire Ring (11:16)
- Project 11: Create a Round Brilliant Diamond & Settings Part 7: Crown-Set Solitaire Ring (11:07)
- Course Wrap Up and Next Steps
Hi, I’m Tali.
I have been developing jewelry tutorials for Rhino 3D via DrawingPost.com for over four years. With my teaching experience, I am now bringing a complete set of courses to you, to share my knowledge and love of mixing jewelry creation and technology through Rhino CAD and 3D printing.
